GoWesty SmartGauge (Tach/Fuel/Temp) [Vanagon]

$250.00
Skip to product information

GoWesty SmartGauge (Tach/Fuel/Temp) [Vanagon]

Product: GVW-TACH-KIT
Works With: 1983-1991
Manufacturer: GoWesty
Availability: Good Stock
Wrench Rating: Requires some hand & power tools and minimal mechanical knowledge.

$250.00

Does this part fit your vehicle? Log in to your account & update your profile!

The GoWesty tach/fuel/temp SmartGauge assembly is a direct replacement for your existing combination gauge, Gowesty Instrument Cluster Circuit Foil Replacement Kit required but NOT included!

Whether you have a tach/fuel/temp or (analog) clock/fuel/temp combination gauge (and would like a tachometer instead of that useless clock), this is an all-in-one, fully electronic solution. If any of the gauges (tach, analogue clock, temp or fuel) in your Vanagon instrument cluster don’t work, there are no new parts available to fix them. Additionally, good used gauges are difficult to find and costly. Even if your gauges are still working, this is an upgrade worth considering. Read on!

Fits:
• 1980-83 Vanagon Aircooled with Bosch EFI or carburetor(s) - Requires oil temp sender
• 1983-91 Vanagon Waterboxer with Bosch EFI, GoWesty EFI, or carburetor(s)
• All watercooled gasoline engine conversions - VW Inline-4, 1.8T, Ford Zetec, Subaru
• VW TDI engine conversions. Does NOT work with “one wire” (non-TDI) diesel engine - Coming soon
•
Engine conversions with single ignition coil/distributor ignition systems
• Selectable for 4,5,6, and 8-cylinder engine configurations

Kit Includes:
• Combination tach/fuel/temp SmartGauge
• Plug-and-play compatibility with the GoWesty Circuit Foil Replacement Kit
• Complete PDF installation instructions via QR code

Features:
• Vintage look combination gauge to match your existing OEM speedometer or our GoWesty Electronic Speedometer
• All new parts. Modern design. Rugged and reliable componentry
• Comes with pre-calibrated fuel and temperature gauges
• Push-button calibration feature for fuel and temp gauges if needed
• Audible and visual alarms for low fuel, high coolant temp, and low coolant level
• Direct fit in the original instrument cluster housing, no modifications to housing required
• 4,5,6 & 8-cylinder engine selectable

Additional important considerations:
• Does not work with the original instrument cluster blue circuit foil
• Does not work with any aftermarket cluster foil replacements except the GoWesty design

The GoWesty SmartGauge is designed to be plug-and-play with our Instrument Cluster Circuit Foil Replacement Kit - just follow the simple instructions included. If your instrument cluster has broken corners, grab our Instrument Cluster Corner Fix Kit for a quick repair. If your cluster has broken mounting tabs, check out our Instrument Cluster Mounting Tab Kit.

Full product article:
Tach/Temp/Fuel Combo Gauge: The GoWesty SmartGauge Solution

  • 5 stars: 15 (100%)
  • 4 stars: 0 (0%)
  • 3 stars: 0 (0%)
  • 2 stars: 0 (0%)
  • 1 star: 0 (0%)
j
jon p.
1986 with a broken clock

my Vanagon had neither a tachometer or a functioning clock. This Tachometer kit is plug and play with the upgraded Instrument Cluster Circuit Foil kit, after 44 years my Van in Tached.

P
Peter C.
Great replacement for the original analog clock

My van originally had an analog clock that never worked instead of the tachometer. I had looked at several other solutions to adding a tach but wanted to keep the original look, when I saw this one it was a no brainer; plus this one comes with an LED and audible warning when gas is getting low! I had previously installed the GoWesty dash foil replacement kit so this was a very easy install. Since my van didn't have an original tach (84' Vanagon) I had to run an additional wire from the coil to the dash to make this work; fortunately this is all included in the instructions so I new what I was getting myself into. I couldn't be more pleased with this tach.

B
Brad J.
Brad

Tach upgrade is terrific. Easy install, clear instructions, and now have a tach that matches the GPS speedometer. Good 21st century engineering.

D
Daniel M.D.L.
Great to finally have a tach!

Very easy install, works as intended, and the coolant temp needle is consistently in the middle for peace of mind!

c
cecil p.

I just completed installing the GoWesty SmartGauge in my 1985 Westy with a Sube conversion. Installation was easy. Start forward. All instruments appear to be working and calibrated from the factory. Very pleased with my purchase.

B
Bernal R.

Great!

S
Shannon J.

This smart gauge was the answer to my tach not working with my Subaru swap. All the other features are insane also! A must have for a water boxer or Subaru swap.

T
Tony

I installed this gauge along with the foil replacement kit. I found the overall installation is relatively easy, but be aware that the video and .pdf instructions are somewhat out of date to the current version of both the products, and do not cover variations found in all years of the Vanagon. Another thing to bear in mind is you'll potentially encounter variances caused by parts substitutions over the years. For example, he speedo in my Vanagon is from a different model year.
My van has a Subaru engine, and it did not have a tachometer from the factory, so I had to run a tachometer signal wire from my Subaru engine control module to the gauge. The .pdf instructions have pin-out diagrams for the foil kit and early and late Vanagons, so I had all the information needed.

h
herman e.

Love it fuel gage works again 👍👍

B
Baba K.

Great gauges, love them

C
Cody T.
Love it

I have the GPS speedometer and the tachometer. Love them both, but on the speedometer I have the option for yellow needles. Does the tachometer have that same option? I couldn't find it

Hi Cody, early GPS speedos had that feature, but all our current speedos and tachometers do not. Instead, we opted to have the option for illuminated or non-illuminated needles. As the instrument cluster housing itself is illuminated, this made more sense. Additionally, one can easily change the color of the cluster illumination by swapping out the LEDs for the desired color. Thank you for your review and your support! GW

A
Anthony S.
Everything works! Finally!

My original tach kinda worked, fuel and temp did not. So this was a needed upgrade. Plus it just looks cool. The needles glow, they sweep and land exactly where they are supposed too. I paired this with blue foil replacement and matching Speedo for a “factory” GoWesty look.

L
Larry G.J.
Larry G Johnson (GW Smart Gauge)

FINALLLLY the tach displays correct and accurate RPMs for the first time in five years. This GW SmartGauge accomodates the six cylinder Subaru conversion and is totally compatible with the prior upgraded GW speedo and VSS components. Happy Vanagon driver....

R
Richard O.
Changed my life

Combined with the dash PCB kit, this has FINALLY sorted everything on my dash -fixing the rev counter, lighting and warning LEDs flashing like a disco. And not only that, added nice style with the modern needles and clear display. These are things that make is a pleasure to drive and less stress!
Absolutely awesome development work from GoWesty.

C
Charles K.
Smart Gauge in 1991 Vanagon

Beautiful design! Fit perfectly.
