[DIGITAL DOWNLOAD] Center Skid Plate [Syncro]

Thumbnail of [DIGITAL DOWNLOAD] Center Skid Plate [Syncro]

[DIGITAL DOWNLOAD] Center Skid Plate [Syncro]

Product:	GVW-SKIDPLATE-CENTER-DD
Works With:	1986-1991
Manufacturer:	GoWesty Engineering

Proposition 65: This product may contain chemicals known to the state of California to cause cancer, birth defects, or other reproductive harm.

THIS PRODUCT IS A DIGITAL DOWNLOAD - NOT A PHYSICAL PRODUCT

Protect your driveshaft and undercarriage with this bolt-on center skid plate – now available as a detailed digital download for DIY fabrication and installation. Designed specifically for all 4WD Vanagon Syncro models, this skid plate offers serious protection without excess weight. This design has proven its strength and reliability under real-world conditions. Build it yourself and get the same protection we trust on our own rigs.

What’s included:

2D fabrication drawings (DXF/PDF)
Installation guide
Hardware specs

Installation Notes:
This design requires drilling through the under-run bars that run alongside the driveshaft. Basic hand tools and a power drill are all you need for installation. Includes all the necessary hardware and detailed installation instructions. This is designed to fit the factory under-run bars. If your under-run bars have been modified, please make sure that this product will still work for you.

As part of our new line of digital download resources, your purchase includes everything you need to build the product yourself—complete with technical drawings and a full bill of materials, including hardware. Whether you're a professional fabricator or a hands-on hobbyist, these files are designed to help you confidently source materials and execute your build with accuracy and efficiency.

Inside the downloadable folder, you may find that some parts come with a DXF file. DXF stands for “Drawing Exchange Format,” and it’s a type of vector file used to describe parts in two dimensions. DXF files are commonly used in design and manufacturing processes, particularly when laser cutting or bending sheet metal is involved.

While we understand that not everyone has access to a laser cutter or press brake, DXF files are still incredibly useful. They provide highly accurate measurements, perfect for anyone building with just a hacksaw and a dream.

To open or modify a DXF file, you’ll need CAD software. Fusion 360 offers a free personal-use version on their website that lets you inspect and customize DXF files. Alternatively, custom sheet metal fabrication services like SendCutSend accept DXF files and can cut and form parts for you.

Have fun fabbing!

This file is for personal use only. It may not be used for any commercial purposes, including but not limited to resale, reproduction, distribution, or incorporation into products for sale. By downloading this file, you agree not to share, sell, or redistribute it in any form.

There are no returns for this digital product. All sales are final.
